COM Express Compact Type 6: conga-TCA5 データシート

製品カタログ

COM Express Compact Type 6

conga-TCA5 は、低消費電力のIntel Atom E3900 (Apollo Lake) プロセッサを搭載した、COM Express Compact Type 6モジュールです。

このカタログについて

ドキュメント名 COM Express Compact Type 6: conga-TCA5 データシート
ドキュメント種別 製品カタログ
ファイルサイズ 849.6Kb
登録カテゴリ
取り扱い企業 コンガテックジャパン株式会社 (この企業の取り扱いカタログ一覧)

この企業の関連カタログ

この企業の関連カタログの表紙
【製品ハイライト】 コンガテック ハイライト2024
製品カタログ

コンガテックジャパン株式会社

この企業の関連カタログの表紙
COM Express Compact Type 6 モジュール: conga-TC700 データシート
製品カタログ

コンガテックジャパン株式会社

この企業の関連カタログの表紙
COM Express Compact Type 6 堅牢版: conga-TC675r データシート
製品カタログ

コンガテックジャパン株式会社

このカタログの内容

Page1

LOW POWER CONSUMPTION conga-TCA5 - Intel® Pentium® Quad Core on COM Express - Enhanced Security Execution - Up to 3 independent Ultra HD displays Formfactor Formfactor COM Express® Compact | (95 x 95 mm) | Type 6 Connector Layout CPU Intel® Pentium® N4200 2.50 GHz (Burst) | 1.1 GHz Clock Quad Core L2 cache 2MB 6W TDP Intel® Celeron® N3350 2.40 GHz (Burst) | 1.1 GHz Clock Dual Core L2 cache 2MB 6W TDP Intel® Atom™ x7-E3950 2.00 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 12W TDP Intel® Atom™ x5-E3940 1.80 GHz (Burst) | 1.6 GHz Clock Quad Core L2 cache 2MB 9.5W TDP Intel® Atom™ x5-E3930 1.80 GHz (Burst) | 1.3 GHz Clock Dual Core L2 cache 2MB 6.5W TDP DRAM 2 SO-DIMM sockets for DDR3L memory modules up to 8 GByte with 1867 MT/s | Dual channel memory interface for increased graphics performance Chipset Integrated in SoC Ethernet Intel i210 (Industrial) /i211 (Commercial) Gigabit Ethernet Controller I/O Interfaces 5x PCIe x1 | 4x USB 3.0 (XHCI) | 8x USB 2.0 (EHCI) | 2x SATA III | LPC | SPI | I²C bus (fast mode 400 kHz | multi-master) | SDIO 2x UART (RX/TX)s | opt. 2x MIPI-CSI Mass Storage opt. eMMC 5.0 onboard flash up to 64 GByte Sound Digital High Definition Audio Interface Graphics Intel® HD Graphics 500 with support for 4k Ultra HD displays | DirectX 12 | OpenGL 4.4 | OpenCL 2.0 | OpenGL ES 3.0 | HDCP 1.4 (wired), HDCP 2.0 (wireless) | Video decode hardware acceleration including support for 4kp60 HEVC (H.265), H.264, MVC, VP8, VP9, VC-1, WMV9, JPEG/MJPEG | Video encode hardware acceleration including support for 4kp30 HEVC (H.265), H.264, MVC, VP8, JPEG/MJPEG. LVDS Dual channel LVDS transmitter | support for flat panels with 2x24 bit data mapping up to a resolution of 1920x1200@60Hz. Digital Display Interface (DDI) Up to 2x DDI (max. 3840x2160 @ 30Hz) | 1x eDP 1.3 (optional) congatec Board Controller Multi Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | BIOS Setup Data Backup I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Control Embedded BIOS Features OEM Logo | OEM CMOS Defaults | LCD Control | Display Auto Detection | Backlight Control | Flash Update | based on AMI Aptio UEFI Security Trusted Platform Module (TPM) optional. Hash and RSA algorithms | key lengths up to 2048 bits | real random number generator Power Management ACPI 5.0 with battery support Operating Systems Microsoft® Windows 10 | Microsoft® Windows 10 IoT Enterprise | Microsoft® Windows 10 IoT Core | Linux | Yocto Power Consumption see user’s guide for full details | CMOS Battery Backup Temperature Commercial : Operating: 0 to +60°C Storage: -20 to +80°C Industrial: Operating: -40 to +85°C Storage: -20 to +80°C Humidity Operating: 10 - 90% r. H. non cond. Storage: 5 - 95% r. H. non cond. Size 95 x 95 mm (3.74” x 3.74”) www.congatec.com
Page2

conga-TCA5 | Block diagram COM Express 2.1 stuffing option COM Express 2.1 AB Connector CD Connector Type 6 Type 6 Intel® ApolloLake Soc DDI to VGA *1 stuffing option CPU Platform VGA Intel® 64 AES-NI DDI0 DDI0 LVDS eDP to LCD I/ F (LVDS) eDP EIST XD LVDS DDI1 DDI1 PCIe Port 0 PCIe0 x1 PCIe1 x1 Integrated Intel® HD Graphics Gen 8 PCIe Port 1 Hardware Graphics Accelerators DDI2 stuffing option 2D 3D PCIe Port 2 Gfx with Burst Technology PCIe Port 3 PCIe Switch *2 PCIe2 x1 Video Codecs PCIe Port 4 H.265/HEVC OpenCL 2.0 PCIe Port 5 stuffing option Dual Channel HDCP 1.4 (wired) OpenGL 4.3 DDR3L 1864 MT/s PCIe3 x1 Ethernet PCIe GBE HDCP 2.0 (wireless) DirectX 12 USB Port 0..7 8x USB 2.0 HEVC OpenGLES 3.0 SuperSpeed 0 VP9 USB 3.0 Port 0 HDA I/F HDA SuperSpeed 1 PAVP 2.0 USB 3.0 Port 1 SATA0 SuperSpeed 2 SATA Port 0 USB 3.0 Port 2 SATA1 SuperSpeed 3 SATA Port 1 Display Interface USB 3.0 Port 3 DisplayPort++ eDP SATA Port 2 SATA Port 3 FWH Audio Interface MIPI CSI SPI SPI HDA SM Bus PEG x16 SM Bus I/O Interfaces UART0 UART PCIe SPI MIPI SDIO PCIe Port 6 UART1 UART SATA USB 2.0 USB 3.0 eMMC eMMC 5.0 PCIe Port 7 SD-Card LPC to UART *1 stuffing option LPC Bus LPC GPIOs MUX GPIOs TPM *1 Note: 3rd Gen congatec I2C Bus I2C System Management *1 Not available by default (assembly option) LID# / SLEEP# Controller LID# / SLEEP# *2 FAN (Watchdog, EEProm...) Available only on product variant with PN: 048513 FAN control www.congatec.com eMMC Feature flash *1 connector *1 SO-DIMM DDR 3L
Page3

conga-TCA5 | Order Information Article PN Description conga-TCA5/i-E3950 048510 COM Express Compact module with Intel® Atom™ x7-E3950 quad core processor with 1.6GHz core frequency up to 2.0GHz, 2MB L2 cache and up to 8GB 1866MT/s DDR3L SODIMM memory support. Industrial grade temperature range from -40°C to 85°C. conga-TCA5/i-E3940 048511 COM Express Compact module with Intel® Atom™ x5-E3940 quad core processor with 1.6GHz core frequency up to 1.8GHz, 2MB L2 cache and up to 8GB 1866MT/s DDR3L SODIMM memory support. Industrial grade temperature range from -40°C to 85°C. conga-TCA5/i-E3930 048512 COM Express Compact module with Intel® Atom™ x5-E3930 dual core processor with 1.1GHz core frequency up to 1.8GHz, 2MB L2 cache and up to 8GB 1866MT/s DDR3L SODIMM memory support. Industrial grade temperature range from -40°C to 85°C. conga-TCA5/N3350 048530 COM Express Compact module with Intel® Celeron™ N3350 dual core processor with 1.1GHz core frequency up to 2.4GHz, 2MB L2 cache and up to 8GB 1866MT/s DDR3L SODIMM memory support. conga-TCA5/N4200 048531 COM Express Compact module with Intel® Pentium® N4200 quad core processor with 1.5GHz core frequency up to 2.5GHz, 2MB L2 cache and up to 8GB 1866MT/s DDR3L SODIMM memory support. conga-TCA5/i-CSP-T 048555 Passive cooling solution for COM Express Compact module conga-TCA5 with lidded Intel Atom processor. All standoffs are M2.5mm thread. conga-TCA5/i-CSP-B 048554 Passive cooling solution for COM Express Compact module conga-TCA5 with lidded Intel Atom processor. All standoffs are with 2.7mm bore hole. conga-TCA5/i-HSP-T 048551 Standard heatspreader for COM Express Compact module conga-TCA5 with lidded Intel Atom processor. All standoffs are M2.5mm thread. conga-TCA5/i-HSP-B 048550 Standard heatspreader for COM Express Compact module conga-TCA5 with lidded Intel Atom processor. All standoffs are with 2.7mm bore hole. conga-TCA5/CSP-T 048557 Passive cooling solution for COM Express Compact module conga-TCA5 with open silicon Intel Pentium and Celeron processor. All standoffs are M2.5mm thread. conga-TCA5/CSP-B 048556 Passive cooling solution for COM Express Compact module conga-TCA5 with open silicon Intel Pentium and Celeron processor. All standoffs are with 2.7mm bore hole. conga-TCA5/HSP-T 048553 Standard heatspreader for COM Express Compact module conga-TCA5 with open silicon Intel Pentium and Celeron processor. All standoffs are M2.5mm thread. conga-TCA5/HSP-B 048552 Standard heatspreader for COM Express Compact module conga-TCA5 with open silicon Intel Pentium and Celeron processor. All standoffs are with 2.7mm bore hole. DDR3L-SODIMM-1866 (2GB) 068730 DDR3L SODIMM memory module with 1866 MT/s and 4GB RAM DDR3L-SODIMM-1866 (4GB) 068731 DDR3L SODIMM memory module with 1866 MT/s and 8GB RAM DDR3L-SODIMM-1866 (8GB) 068732 DDR3L SODIMM memory module with 1866 MT/s and 8GB RAM DDR3L-SODIMM-1866 (2GB) 068733 Industrial DDR3L SODIMM memory module with 1866 MT/s and 2GB RAM / i-temp DDR3L-SODIMM-1866 (4GB) 068734 Industrial DDR3L SODIMM memory module with 1866 MT/s and 4GB RAM / i-temp DDR3L-SODIMM-1866 (8GB) 068735 Industrial DDR3L SODIMM memory module with 1866 MT/s and 8GB RAM / i-temp Accessories conga-TEVAL 065810 Evaluation carrier board for Type 6 COM-Express-modules conga-LDVI/EPI 011115 LVDS to DVI converter board for digital flat panels with onboard EEPROM This Datasheet should be read in conjunction with "Errata sheet - congatec xA5 designs", available in the document section of congatec’s webportal. ©2021 congatec GmbH. All rights reserved. All data is for information purposes only. Although all the information contained within this document is carefully checked, no guarantee of correctness is implied or expressed. Product names, logos, brands, and other trademarks featured or referred are the property of their respective trademark holders. These trademark holders are not affiliated with congatec. Rev. Mar 17, 2021 CE www.congatec.com
