TuffCORD Onboard Recording System

Page 1:Onboard Recording System© 2016 Ampex Data Systems CorporationFeatures Greater than 200MB/s sustainednetwork throughput Standard Dual Gigabit EthernetInterfaces Memory Module Capacities to 2TB AES Encryption using FIPS 197Validated Hardware & Software Built for Rugged, MIL-STD-810Environments with MIL-STDPower and Connectors Options for Additional orCustomized I/OThe TuffCORD™ is a rugged, efficient networkrecorder, file server and data loader.Built for tough environments, the TuffCORD goeswherever operators need to go, and deliversconsistent, reliable performance in challengingconditions. With its compact size, light weight, lowpower dissipation and mounting options, it can beinstalled wherever it needs to be.Designed for Information AssuranceThe TuffCORD has been designed from the ground upto provide cybersecurity capabilities that meet the real-world needs of operators. By leveraging world-classsolutions from trusted suppliers, the system isstraightforward to incorporate into a complete Operation Security plan.Performance and CapacityGigabit Ethernet has become the default networking technology for onboard data storage applications, andthe TuffCORD provides two 1000Base-T interfaces, as well as expansion capability for options for video andother bus types, including MIL-STD-1553B, CAN bus, and even WiFi networking.To support this range of interfaces, the TuffCORD provides a single high-capacity, high performanceremovable memory module, with capacities from 240GB to 2000GB (2TB) and higher, as memorytechnology matures. The memory modules leverage rugged COTS media solutions, further qualified byAmpex to meet the requirements of challenging programs.Each memory module offers performance in excess of 250MB/second sustained, providing a recordingduration of nearly three hours at the maximum operational bandwidth.Open System, Trusted EnvironmentsThe heart of the TuffCORD is a standardized, ruggedpluggable processing module, integrating the CPU withmemory and conventional I/O interfaces such as PCIExpress, USB, Ethernet and serial ports. This modulefacilitates product reliability and long-term supply by isolatingthe intricacies of the CPU from the overall system; as CPUtechnology evolves, alternative modules can be used withoutchanging the system’s internal and external interfaces.Two CPU models are available, each a member of the IntelAtom™ “Bay Trail-I” family; both CPUs feature 64 bitprocessing and, critically, the “AES New Instructions”. Usingvalidated software modules, this capability facilitates high-speed encryption and decryption in accordance with theAdvanced Encryption Standard (AES, FIPS 197) andtherefore a part of a FIPS 140-2 solution.Expansion and OptionsThe TuffCORD is designed to be flexible and versatile. In addition to the dual gigabit Ethernet interfaces, thesystem is designed to support expansion for additional interfaces, including more Ethernet interfaces,MIL-STD-1553B, and even WiFi networking. The storage module has been designed to be modular, so thatadditional or different storage media types can be provided as required. As with all Ampex products, acomplete ecosystem is available including ground support equipment to facilitate data transfer to and fromthe recording media. Contact Ampex for more information.

Page 2:Onboard Recording SystemTel: 1-800-752-7590www.ampex.com E-mail: sales@ampex.com Fax: 1-650-367-3106Ampex Japan Ltd. Tel: 81-3-6433-9081 Fax: 81-3-6433-9245 E-mail: info@ampex.co.jpAmpex Data Systems Corporation is AS 9100B / ISO 9001:2008 CertifiedRev B 02/16TuffCORD Block DiagramSpecifications1SystemCPU Subsystem: Intel Atom E3800 Series:Option 1: E3845, Quad Core, 2MB Cache, 1.91GHz, 4GB ECC DDR3L-1333 Memory, TPM 1.2Option 2: E3805, Dual Core, 1MB Cache, 1.33GHz, 2GB ECC DDR3L-1066 Memory, TPM 1.2Network Interfaces: Two 1000Base-T Gigabit EthernetOptional Interfaces: Additional Gigabit Ethernet ports, Video, MIL-STD-1553B, OthersFixed Storage: Write-protected Firmware/OS Device Plus Separate Configuration/Logging DeviceRemovable Storage: Removable Media ModuleNetwork Protocols: NFSv4, NFSv3, CIFS/SMB, FTP, TCP, UDPOperating system: Red Hat Linux 7 (DISA STIG compliant)RMM Storage Capacity: Up to 2000GB (2TB)Encryption: Advanced Encryption Standard (AES), 256 bit keys, FIPS 197 ValidatedPerformanceInternal Data Rate: 250 MByte/sec (sustained, to RMM)NFS Data Rate: 200 MByte/sec sustained (read or write)PowerPower: 28VDC per MIL-STD-704A with under/over voltage protectionDissipation (Full Load): 15W (E3845 CPU) / 8W (E3805 CPU)MechanicalDimensions: 3.6” H x 4.8” W x 6.3” D (92mm x 122mm x 160mm), extends 6.0 (152mm)” behind mounting panelMounting: Panel mount (6x standard “Quarter Turn” fasteners) or base mountWeight (System): 5.5lbs (2.5Kg)EnvironmentalTemperature: Operating (Extended Range) -40ºC to 71ºCNon-operating: -45ºC to 85ºCHumidity: 0% to 95% RH (MIL-STD-810E, Procedure III)Vibration: 4.6grms (active) / 9.8grms (endurance), MIL-STD-810EShock: 20g (half sine, 11ms), MIL-STD-810EEMI Compatibility: MIL-STD-461F1Specifications subject to change without noticeProcessor ModuleCPU4GB ECCDDR3LMemoryi210 GbEPCIe v2 x1i210 GbEPCIe v2 x2 (Expansion)PCIe v2 x1AES-NI Intel 64SATA-2Removable Memory Module SATA-2 (Expansion)USB to SerialConsole PortDual SDIOBridgeFirmwareSSDConfig /Log SSD USB 2.0USB 2.0USB3.0(Expansion)SDIO BridgeUSB 2.0WiFiSwitchWrite ProtectTPMDiagPortUSBGigabitEthernet
