JP EN Modula LIFT Think Vertical, Think Modula www.modula.com

Modula / Modula LIFT Modula: your Vertical Lift Module Modula are automatic vertical lift modules with trays, based on the concept of vertical storage and space saving on the ground. They can reach a unit height of 16,1 metres high and hold up to 90.000 kg. They can store all types of materials in a secure, clean, efficient manner, and they allow a ground surface area saving of up to 90%. Modula have over 30 years’ experience as an Italian company boasting the highest technology lines: a real smart factory 4.0. / Without Modula / With Modula / Floor space recovery / up to 90% 1. RECOVER SPACE 2. INCREASE SECURITY 3. SAVE TIME 4. IMPROVE EFFICIENCY 5. REDUCE RISKS 6. BOOST INVENTORY MANAGEMENT 2

THROUGHPUT OF SELF-CENTERING PULLEYS UP TO 120 TRAYS/HOUR TRAY ADJUSTABILITY EAGLE SELF-CENTERING V-SHAPE BELT PLASTIC-COATED STEEL LOAD-BEARING STEEL EXTERIOR PANELS STRUCTURE TOUCH SCREEN OPERATOR CONSOLE SIMPLE, INTUITIVE SOFTWARE Technical Specifications Unit heights: from 3.300 mm to 16.100 mm Throughput: up to 120 trays/hr (depending on the configuration) Unit height increment: 200 mm Operator interface: industrial console with 10.4’ ’touch screen (Copilot) Tray storage pitch: 25 mm Number of bays: up to 3, also above ground level and on the same side Tray widths: from 1.500 mm to 4.100 mm Types of bay: internal or external with single or dual delivery level • Minimal energy consumption Tray depths: 654 mm & 857 mm • Automatic return tray weight check • Dynamic tray storage height Gross total payload: For standard machine with 1 bay, actual gross load is • Load-bearing structure in galvanised steel 70,000 kg ( standard structure) and 90,000 kg ( with reinforce structure) • Eagle steel-reinforced toothed belt transmission 6. BOOST INVENTORY MANAGEMENT • Elevator guide system with 6 rollers per side Maximum storage height capacity: 695 mm (bay S) / 895 mm (bay M) / 1,295 mm (bay XL) • Multiple payload tray management 3 25mm 25mm 25mm

Modula / Modula LIFT Modula’s tray configurations You can configure the Modula in different ways according to how you plan to use it, with different types of picking bays. • Single bay • Double bay • Internal bay • External bay • Opposite bay • Displaced bay With Modula you can select the dual delivery level to work on two trays at the same time (while one is in the bay, the other is preparing the subsequent picking), or with an external bay which facilitates worker activity if he is using mechanical aids like forklifts, zero-weight cranes or overhead hoists. You can also carry out picking simultaneously on two sides of the machine or have access to trays in different levels. Single internal delivery Single external delivery Dual internal delivery Dual external delivery 4

What can you store in a Modula? Whatever your industrial sector, Modula lets you store any type of product or spare part, in different sizes, weights, heights and volumes. What do companies usually stock? • Spare parts • Small items • Products or consumer goods for distribution or sale • Finished and semi-finished products • Tools, equipment, cosmetics, pharmaceuticals • Electrical and electronic materials • Mechanical parts • Boxes and much more. Tooling and drill bits Reels and electronic components Pharmaceuticals, boxes and cosmetics Mechanical instruments Tools and spare parts Small parts and hardware Bottles and labels Spools, rope, chains 5

Modula / Modula LIFT Our models ME & ME-D rint Model Tray width Unit footp Tray depth Tray wall Net tray Unit footprint (mm) with EXTERNAL (mm) height payload with INTERNAL (mm) (kg) bay (Width x bay (Width x Depth mm) Depth mm) ME25 1,500 654 45 / 70 / 120 250 1,917x2,556 1,917x3,246 ME25D 1,500 857 45 / 70 / 120 250 1,917x3,165 1,917x4,058 ME50 1,500 654 70 / 120 500 1,917x2,556 1,917x3,246 ME50D 1,500 857 70 / 120 500 1,917x3,165 1,917x4,058 ME75 1,500 654 70 / 120 750 1,917x2,556 1,917x3,246 1.917 mm ME75D 1,500 857 70 / 120 750 1,917x3,165 1,917x4,058 ME1000 1,460 654 70 / 120 990 1,917x2,556 1,917x3,246 ME1000D 1,460 857 70 / 120 990 1,917x3,165 1,917x4,058 MA & MA-D tray Unit footprint Unit footprint Model Tray width Tray depth Tray wall Net (mm) height payload with INTERNAL with EXTERNAL (mm) (mm) (kg) bay (Width x bay (Width x Depth mm) Depth mm) MA25 1,900 654 45 / 70 / 120 250 2,317x2,556 2,317x3,246 MA25D 1,900 857 45 / 70 / 120 250 2,317x3,165 2,317x4,058 MA50 1,900 654 70 / 120 500 2,317x2,556 2,317x3,246 MA50D 1,900 857 70 / 120 500 2,317x3,165 2,317x4,058 MA75 1,900 654 70 / 120 750 2,317x2,556 2,317x3,246 2.317 mm MA75D 1,900 857 70 / 120 750 2,317x3,165 2,317x4,058 MA1000 1,860 654 120 990 2,317x2,556 2,317x3,246 MA1000D 1,860 857 120 990 2,317x3,165 2,317x4,058 MC & MC-D int Unit footprint Model Tray width Tray depth Tray wall Net tray Unit footpr (mm) ght payload with INTERNAL with EXTERNAL (mm) hei (mm) (kg) bay (Width x bay (Width x Depth mm) Depth mm) MC25 2,500 654 45 / 70 / 120 250 2,917x2,556 2,917x3,246 MC25D 2,500 857 45 / 70 / 120 250 2,917x3,165 2,917x4,058 MC50 2,500 654 70 / 120 500 2,917x2,556 2,917x3,246 MC50D 2,500 857 70 / 120 500 2,917x3,165 2,917x4,058 MC75 2,500 654 70 / 120 750 2,917x2,556 2,917x3,246 2.917 mm MC75D 2,500 857 70 / 120 750 2,917x3,165 2,917x4,058 MC1000 2,460 654 120 990 2,917x2,556 2,917x3,246 MC1000D 2,460 857 120 990 2,917x3,165 2,917x4,058 6

MX & MX-D nt Model Tray width Tray depth Tray wall Net tray Unit footpri (mm) ERNAL Unit footprint (mm) height payload with INT (mm) (kg) bay (Width x with EXTERNAL Depth mm) bay (Width x MX25 3,100 654 45 / 70 / 120 250 3,517x2,556 3,517x3,246 MX25D 3,100 857 45 / 70 / 120 250 3,517x3,165 3,517x4,058 MX50 3,100 654 70 / 120 500 3,517x2,556 3,517x3,246 MX50D 3,100 857 70 / 120 500 3,517x3,165 3,517x4,058 MX75 3,100 654 70 / 120 750 3,517x2,556 3,517x3,246 3.517 mm MX75D 3,100 857 120 750 3,517x3,165 3,517x4,058 MX1000 3,060 654 120 990 3,517x2,556 3,517x3,246 MX1000D 3,060 857 120 990 3,517x3,165 3,517x4,058 ML & ML-D otprint Unit footprint Model Tray width Tray depth Tray wall Net tray Unit fo (mm) h INTERNAL with EXTERNAL (mm) height payload wit (mm) (kg) bay (Width x bay (Width x Depth mm) Depth mm) ML25 4,100 654 70 / 120 250 4,517x2,556 4,517x3,246 ML25D 4,100 857 70 / 120 250 4,517x3,165 4,517x4,058 ML50 4,100 654 120 500 4,517x2,556 4,517x3,246 ML50D 4,100 857 120 500 4,517x3,165 4,517x4,058 ML75 4,100 654 120 750 4,517x2,556 4,517x3,246 4.517 mm ML75D 4,100 857 120 750 4,517x3,165 4,517x4,058 ML1000 4,060 654 145 990 4,517x2,556 4,517x3,246 ML1000D 4,060 857 145 990 4,517x3,165 4,517x4,058 MAXIMUM PAYLOAD MODULA WMS OPERATOR SAFETY: FOR ALL TRAYS: INDUSTRIAL COPILOT SOFTWARE: ERGONOMIC, SAFE, UP TO 990 KG CONSOLE: TO HAVE EVERYTHING TUV CERTIFICATION PER TRAY 10.4 INCH TOUCH UNDER CONTROL SCREEN 7

Modula / Modula LIFT Modula integrates with all technology Modula is ideal for those who also need complete integration with other technologies such as: • Robots • Roller conveyor • Put-To-Light systems • Manipulators • Zero Weight cranes. Thanks to Modula WMS warehouse software, your VLM can be integrated with all ERP systems to connect the warehouse Modula into the company workflow and make it interact with the management system. This way you can manage the materials and users registries, production orders, stocks, spare parts, and you can better check on stocks and all warehouse movements: picking and restoring. With Modula, taking inventory is very easy, while producing dedicated analyses and reports to have everything under control. Integration with anthropomorphic robots Put-to-Light systems connected to WMS Integration with manipulators and cranes Integration with conveyors Insulated machines for outdoor installation Fire protection system integration 8

Options Magnetic badge Reader EKS Reader Laser Pointer Put-to-Light 1D or 2D barcode Reader Sliding console Automatic door Electrified tray Foot bar task complete End Picking Button External bay lighting RFID Reader Alphanumeric bar 9

Options LED bar ESD protection system Label printer Counting scale Telescopic bay Trolley Picking cart Tray accessories Weight distribution plates SLOT TRAY PARTITIONS DIVIDERS Modula Green 0 °C Sprinkler predisposition Remote electrical panel 10

Some Modula references AFFILIATED HOSPITAL OF GUANGXI MEDI UNIVERSITY China BMW China, Germany,Austria,UK, Belgium, USA,Mexico,Canada XI’AN INTERNATION MEDICAL CENTER China VOLKSWAGEN China, Germany, Spain, Argentina TCI China DAIMLER China, Italy , Germany, Mexico ABBOTT Italy, France, USA F E R R ARI Italy AKZO NOBEL Italy CHEMICAL AUTOMOBILI LAMBORGHINI Italy BAYER Germany, Argentina, Mexico AUTOMOTIVE M ASERATI Italy PHARMACEUTICAL DUPONT USA INDUSTRIAL J AGUAR Netherlands GLAXO SMITH KLINE Italy, UK, USA A UDI Spain,Mexico, Belgium JOHNSON & JOHNSON USA, Brasil FORD USA, Canada, Spain, Mexico, Turkey HAWE HYDRAULIC China P EUGEOT-CITROEN France PEM PENN ENGINEERING China OPEL Spain GEA BOCK COMPRESSORS China R ENAULT Spain, France, UK BITZER REFRIGERATION China FIAT Italy, Poland, Brasil, Serbia BOSCH REXROTH Italy, Germany, USA, Mexico, India GENERAL MOTORS USA HYDRAULIC VAILLANT GROUP France, UK TATA MOTORS LIMITED India H ARLEY DAVIDSON USA DUCATI MOTOR Italy CRRC China B REMBO Italy, Poland, USA, Czech Republic DHL Spain, Australia TRW AUTOMOTIVE Italy, USA FEDEX USA GKN DRIVELINE Italy, Spain, USA, UK, Poland CONTITECH Germany, Romania, Hungary, Serbia, Mexico TRANSPORT ROBERT BOSCH USA, Germany, Mexico, Spain, Hungary LUFTHANSA TECHNIK China, Germany THYSSENKRUPP ENGINE China, Brasil CHINA ACADEMY OF SPACE TECHNOLOGY China VALEO Italy, Spain, France, Belgium, Turkey, India BEIJING SATELLITE China FAURECIA Italy, Spain, France, USA SICHUAN AIRLINES China MAGNETI MARELLI Italy CHINA EASTERN AIRLINES China MUBEA Germany,Poland,Czech Republic,USA,Mexico AERONAUTICS/ AIRBUS USA, France CATERPILLAR Italy, USA, Belgium AEROSPACE BOEING USA BOMBARDIER Germany China CONTINENTAL Germany, USA BYD China EMBRAER Brasil EUTRON China GE AVIATION USA GREAT WALL PC China, India LOCKHEED MARTIN USA, UK COMMSCOPE China, Italy UNITED AIRLINES USA ELECTRONIC SPIRAXSARCO SCHNEIDER ELECTRIC China, Spain, Indonesia SIEMENS China, Spain, USA, Serbia, India TETRA PAK China PROFACE China PROVOL PACKING China BSH ELECTRICAL China CELESTICA China, Spain, Mexico,Romania, Malaysia PACKAGING BARCO VISUAL China UNISTEEL China China MINGHUA MOULD&PLASTICS China HAIER GROUP INTERNATIONAL PAPER USA INFINEON Portugal, Singapore, Malaysia KIMBERLEY-CLARK USA GARMIN USA SAINT-GOBAIN China,USA GENERAL ELECTRIC France, Israel PLASTIC / PAPER EATON CORPORATION USA, Mexico, Singapore FOXCONN Czech Republic DELL USA IKEA China LYRECO Italy, Spain, Germany, Poland, Belgium FURNITURE AGCO China,Italy,Spain,USA BONFIGLIOLI RIDUTTORI China, Italy, Germany, USA, Slovakia, India HONEYWELL China, Italy, Romania, Mexico, Slovakia, South Korea DANIELI China, Italy, Russia, Thailand DECATHLON Canada MACHINERY PRIMA POWER China, Italy AMAZON USA MARPOSS China, Italy, Germany BOLLHOFF China SUPERMARKET/ GETRAG TRANSMISSION China E-COMMERCE BITZER China, Germany KROHNE China OISHI - LIWAYWAY China LAEPPLE China YILI GROUP China COCA COLA Germany, UK, USA, Chile, Malaysia GUHRING China FERRERO Italy, France, Turkey TIANHONG MACHINERY China FOOD PEPSICO USA, Australia SCHAEFFLER China, Romania DRINKS DEUTZ FAHR MACHINERY China IRO - WUX I China 3M USA, Poland PRADA Italy ABB Italy, Poland, Argentina LOUIS VUITTON Italy BLACK & DECKER USA, Canada GIORGIO ARMANI Italy ELECTROLUX Italy, USA, Hungary HERMES Italy FANUC Italy, Hungary, Russia CLOTHING/ LUXOTTICA Italy ROLLON Italy, Germany FASHION DIOR Italy SEW France VALENTINO Italy NIKE USA, Belgium, Netherlands 11

Modula Modula World Modula is present in 5 continents with dealers and branches located in over 50 countries 製品に関するお問い合わせは以下の担当者にお気軽に MODULA (CHINA) AUTOMATION EQUIPMENT CO.,LTD ご連絡お願いします。 N.7, Fangzhou Road, Suzhou Industrial Park, Jiangsu Province, China Modula（モジューラ）日本連絡事務所 Tel. 　佐竹智宏 　Tel. 070-1585-0106 　email: tomohiro.satake@modula.com All information provided on this catalogue is for informative purposes only and is not binding. Modula reserves the right to change information on this catalogue at any time. Modula will not accept liability for or guarantee the accuracy of the information contained herein. LIFT / MAY 2024
