OCP準拠のAC/DCコンバータ

製品カタログ

電子部品・機構部品等の輸出入卸売販売 日本ミックAC/DCコンバータのご案内です。

OCP(オープンコンピュートプロジェクト)規格にて推奨されている
フロントエンドAC/DC電源(SPAFCBK-14G)

◆詳細はカタログをダウンロードしてご覧下さい。

このカタログについて

ドキュメント名 OCP準拠のAC/DCコンバータ
ドキュメント種別 製品カタログ
ファイルサイズ 1Mb
登録カテゴリ
取り扱い企業 日本ミック株式会社 (この企業の取り扱いカタログ一覧)

このカタログの内容

Page1

The SPAFCBK-14G is a power-factor-corrected (PFC) power supply that converts standard AC mains power into a main output of 12 VDC for powering intermediate bus architectures (IBA) in high performance and reliability servers, routers, and network switches. The SPAFCBK-14G meets international safety standards and displays the CE-Mark for the European Low Voltage Directive (LVD).  Open Compute (OCP) compliant  Meeting 80 Plus “Platinum” Efficiency  Wide input voltage range: 90 - 264 VAC  AC input with power factor correction  Always-On 10 W standby output (3.3 V/3 A)  Hot-plug capable  Active current share  Small form factor: 54.5 x 40.0 x 321.5 mm  I2C communication interface for control, programming and monitoring with PSMI and PMBus™ protocol  Overtemperature, output overvoltage and overcurrent protection  High Performance Servers  Routers  Switches
Page2

2 SPAFCBK-14G SPAFCBK-14G 750 W 90 - 264 VAC 12 VDC N: Normal* * Rear to front PARAMETER CONDITIONS / DESCRIPTION MIN NOM MAX UNITS 300 VAC Input Voltage Duration 100 ms Operating Temperature -5 55 °C Storage Temperature Non-operational -40 85 °C Input to Case Basic Insulation Safety Rating Input to Output Reinforced Output to Case Functional Input to Case 2121 VDC Electric Strength Test Voltage Input to Output 2121 VDC (Hi-Pot) Output to Case 707 VDC Input Operating Range Universal Input 90 115/230 264 V Input Frequency 47 50/60 63 Hz Turn-On Voltage 90 V Turn-Off Voltage 70 80 V Maximum Current at VIN = 100 V 11 A Input Current Maximum Current at VIN = 200 V 6 A Turn-on Delay AC on 1 3 sec Enable / Inhibit 150 200 ms @ cold turn-on 35 A AC Line Inrush Peak Current @ hot turn-on 50 A Power Factor Typical, meets EN61000-3-2 0.99 Io (100 %) 91 Efficiency 230 V Io (50 %) 94 % Io (20 %) 90 @ full load, low line 16 Hold Up Time ms @ 60% load 20 Startup Time @ 120 VAC, 60 Hz 3 sec AC Leakage Current @ 264 VAC 3.5 mA Input Fusing Non-user replaceable fuse in the live line 12.5 A tech.support@psbel.com
Page3

SPAFCBK-14G 3 PARAMETER CONDITIONS / DESCRIPTION MIN NOM MAX UNIT Output Voltage V1 Output Voltage 12 VDC Output Current 62 ADC Output Power 750 W Set Point Accuracy -1 +1 % Output voltage variation as input voltage changes Line Regulation ±1 % from 85 V to 264 V with 50 % load Load Regulation Output voltage variation as load changes from 0 to 100 % ±3 % Total Output Voltage Range 11.64 12.36 V IOUT changes 50 % of full load starting anywhere Transient Response from 0 % to 50 % load, at slew rate of 1 A/s Peak Deviation Di/Dt=1A/us 50% full load change 3 4.2 % Settling Time Time until VOUT returns to regulation requirements 0.5 ms Ripple and Noise Periodic and Random Deviation PARD ,DC to 200 MHz Low Line and Full Load Differential Mode 120 mVp-p Worst Case Condition Differential and Common Mode 120 mVp-p External Capacitance Output Capacitance, 12V main output 500 11000 uF Input Under Voltage 85 90 V Output Over Voltage Over voltage Limit, latch off 13.4 14.5 V Output Current-limit Inception 120 150 % Over-Temperature Warning and T(shut)-2 °C Shutdown Output Voltage V2 Output Voltage 3.3 VDC Output Current 3 ADC Set Point Accuracy 1 % Total Output Voltage Range 3.14 3.3 3.46 V Ripple and Noise Periodic and Random Deviation PARD DC to 200 MHz Low Line and Full Load Differential Mode 45 mVp-p Worst Case Condition Differential and Common Mode 45 mVp-p External Capacitance 3V3 standby 20 1000 uF Input Under Voltage 80 90 V Output Over Voltage Over voltage Limit, latch off 3.6 3.9 V Output Current-limit Inception 120 150 % Turn-On / Turn-Off Defined as time between after application of AC input Turn-On Delay 3 sec (operating range) and Vout rising to 90% of final value. The output rise time is measured from 10% of Vnom to the Output Voltage Rise Time 100 ms lower limit of the regulation band. Rate of output rise – dv/dt The output rise is Monotonic. 100 V/sec Turn-On Overshoot 5 % Turn-Off Undershoot Measured with IOUT = 4 A and no external load capacitor Turn-on Response Time 5 400 ms Measured with IOUT = 38.5 A and 5000 F capacitive load Asia-Pacific Europe, Middle East North America +86 755 298 85888 +353 61 225 977 +1 408 785 5200 © 2016 Bel Power Solutions & Protection BCD.00649_AA
Page4

4 SPAFCBK-14G The following section defines the input and output signals from the power supply. All digital signals should be compatible with +3.3 volt LVTTL logic levels. All control signal lines share the same return used for +3.3 volt standby (3.3 VSB). 5.1 POWER SUPPLY ENABLE (PS_ON) The PS_ON signal is required to remotely turn on/off the power supply. PS_ON is an active low, below 0.7 V signal that turns on the 12 VDC power rail. In the low state this input will not source more than 4 mA of current. The 12 VDC output will be disabled when this input is driven higher than 2.1 V, or open circuited. See PS_ON Signal Characteristics Table. Accepts an open collector/drain input from the system. Signal Type: Input signal to the power supply Pull-up to 3.3 VSB located in power supply. PS_ON = Low, PS_KILL = Low ON PS_ON = Low, PS_KILL = Low OFF PS_ON = Low, PS_KILL = Open OFF MIN MAX Logic level low (power supply ON) 0 V 0.7 V Logic level high (power supply OFF) 2.1 V 3 V Output Source current, VPS_ON_L= low 4 mA Table 1. PS_ON Signal Characteristics 5.2 POWER OK (PW_OK) PW_OK is a power ok signal and will be pulled HIGH by the power supply to indicate that all the outputs are within the regulation limits of the power supply. When 12 VDC main output is < 10.9 V or > 13.2 V, or if any of the outputs fail due to over current protection, over voltage protection, over temperature, or fan failure then this output will be driven LOW. In the event AC mains power is lost, this signal must be driven LOW at least 20mS before the +3.3 VSB output is lost. The output will be an open collector/drain. It will be capable of driving the output below 0.4V with a load of 4 mA. The start of the PW_OK delay time is inhibited as long as any power supply’s 12 VDC output is in current limit. See PW_OK Signal Characteristics Table below. Open collector/drain output from the power supply. Signal Type: Output signal from the power supply Pull-up to 3.3V located in power supply. PW_OK = High Power OK PW_OK = Low Power Not OK MIN MAX Logic level low voltage, Isink = 4ma 0 V 0.4 V Logic level high voltage, Isource = 200μA 2.4 V 3.3 V Input Sink current, PW_OK = Low 4 mA Output Source current, PW_OK = High 2 mA PW_OK delay: (T9) TPW_OK_ON 100 ms 1000 ms PW_OK rise and fall time (w/o decoupling cap) 100 μs Power down delay: (T10) TPW_OK_OFF_12V 1 ms 700 ms Table 2. PW_OK Signal Characteristics tech.support@psbel.com
Page5

SPAFCBK-14G 5 5.3 INPUT VOLTAGE OK (AC_OK) This signal will be asserted, driven HIGH by the power supply to indicate that the input voltage meets the minimum requirements. After falling outside the input voltage requirements for more than 20 mSec, the signal must be driven Low. The output will be an open collector/drain. It will be capable of driving the output below 0.4 V with a load of 4 mA. See AC_OK Signal Characteristics Table below. Open collector/drain output from the power supply. Signal Type: Output signal from the power supply Pull-up to 3.3V located in power supply. AC_OK = High AC OK AC_OK = Low AC Low (Not OK) MIN MAX Logic level low voltage, Isink = 4ma 0 V 0.4 V Logic level high voltage, Isource = 200μA 2.4 V 3.3 V Input Sink current, AC_OK = Low 4 mA Output Source current, AC_OK = High 2 mA AC_OK delay: (T13) TAC_OK_ON 1500 ms AC_OK rise and fall time (w/o decoupling cap) 100 us AC_OK delay: (T8) TAC_OK_OFF 20 ms Table 3. AC_OK Signal Characteristics 5.4 PS_KILL This pin is used to force the 12 V main output off if the supply is removed from the system. At the system level this pin will be connected to the output return directly. When this input is low the power supply will operate. If the input is floating the 12 V main output will turn off while the 3.3 VSB will remain on. This signal overrides all other on-and-off signals. On the power supply connector, this pin is shorter than the others so it is a last-make and first-break contact. See PS_KILL Signal Characteristics Table below. Accepts a ground input from the system. Signal Type: Input signal to the power supply Pull-up to 3.3V located in the power supply. PS_KILL = Low, PS_ON = Low ON PS_KILL = Open, PS_ON = Low or Open OFF PS_KILL = Low, PS_ON = Open OFF MIN MAX Logic level low (power supply ON) 0 V 1.0 V Logic level high (power supply OFF) 2.0 V 3.3 V Source current, VPSKILL = low 4 mA Table 4. PS_KILL Signal Characteristics Asia-Pacific Europe, Middle East North America +86 755 298 85888 +353 61 225 977 +1 408 785 5200 © 2016 Bel Power Solutions & Protection BCD.00649_AA
Page6

6 SPAFCBK-14G 5.5 PRESENT The PRESENT signal is used to sense the number of power supplies in the system (operational or not).This signal is connected to the power supply’s output ground. See PRESENT Signal Characteristics Table below. Output from power supply that is connected to ground. Signal Type: Output signal from the power supply Pull-up to 3.3V located in system. PRESENT = Low Present PRESENT = High Not Present MIN MAX Logic level low voltage, Isink=4mA 0 V 0.4 V Logic level high voltage, Isink = 50μA 3.3 V Sink current, PRESENT = low 4 mA Sink current, PRESENT = high 50 uA Table 5. PRESENT Signal Characteristics 5.6 SMBAlert This signal indicates that the power supply is experiencing a problem that the user should investigate. This may be asserted due to Critical events or Warning events. See PSMI specification for further details. Open-drain output from power supply that is connected to ground. Signal Type: Output signal from the power supply Pull-up to 3.3VSB located in system. SMBAlert = Low Not Present SMBAlert = High Present MIN MAX Logic level low voltage, Isink = 4mA 0V 0.4V Logic level high voltage, Isink = 50μA - 3.3V Sink current, SMBAlert = low - 4mA Sink current, SMBAlert = high - 50μA Table 6. SMBAlert Signal Characteristics 5.7 POWER SUPPLY INTERFACE (PMBUS) The PMBUS interface uses a serial SMBus interface for communication between the power supply(s) and the system. PMBUS allows the system to access status and power sensors in the power supply. The power sensors monitor both input and output power. The status monitors various critical and non-critical conditions in the power supply. One pin is the Serial Clock (SCL). The second pin is used for Serial Data (SDA). Both pins are bi-directional and are used to form a serial bus. Output from power supply that is connected to ground. Signal Type: Output signal from the power supply Pull-up to 3.3VSB located in system. MIN MAX Logic level low voltage, Isink = 4mA 0V 0.4V Logic level high voltage, Isink = 50μA - 3.3V Sink current, SCL and SDA = low - 4mA Sink current, SCL and SDA = high - 50uA Table 7. SCL and SDA Signal Characteristics tech.support@psbel.com
Page7

SPAFCBK-14G 7 5.8 POWER SUPPLY ADDRESSING This signal indicates that the power supply address locations will be determined by external settings through the PS_A0 and PS_A1 address signals. Accepts a ground input from the system. Signal Type: Output signal from the power supply Pull-up to 3.3V located in the power supply. MIN MAX Logic level low voltage, Isink = 4mA 0V 0.4V Logic level high voltage, Isink = 50μA - 3.3V Sink current, PS_A0 and PS_A1 = low - 4mA Sink current, PS_A0 and PS_A1 = high - 50uA Table 8. PS_A0 and PS_A1 Signal Characteristics PS_A1 PS_A0 PSU_ID (MCU) Address EEPROM Address 0 0 B0 A0 0 1 B2 A2 1 0 B4 A4 1 1 B6 A6 Table 9. Address Matrix 5.9 LOAD SHARING CONTROL The power supplies load share by using a single load share bus signal (ISHARE) connected between the power supplies for the 12V output. If the load sharing is disabled by shorting the load share bus to ground, the power system must continue to operate within regulation limits for loads less than or equal to the maximum specified. The failure of a power supply should not affect the load sharing or output voltages of the other supplies still operating. 5.10 LOAD SHARE SIGNAL CHARACTERISTICS The load share signal provides both output current information and the load sharing function. The characteristics of the load share signal are defined below in the following table: ITEM DESCRIPTION MIN NOM MAX UNITS Voltage of load share bus at specified max output Vshare; Iout = max - 8 - V current. dVshare/dIout; Iout >1A Slope of load share bus voltage with changing load. - 8 / Ioutmax - V / A Amount of current the load share bus outputs from Ishare sink; Vshare = 8V - - 0.5 mA each power supply sink. Amount of current the load share bus outputs from 4.0 I share source; Vshare = 8V - - mA each power supply source. Delay from output voltages in regulation to load Tshare; Iout = max sharing active with maximum load of one power - - 100 mSec supply and two power supplies in parallel. Table 10. Load Share Bus Output Characteristics Asia-Pacific Europe, Middle East North America +86 755 298 85888 +353 61 225 977 +1 408 785 5200 © 2016 Bel Power Solutions & Protection BCD.00649_AA
Page8

8 SPAFCBK-14G Figure 1. Timing Diagram PARAMETER MIN TYP MAX UNITS CONDITION / COMMENTS T1 (Tout_rise) - - 100 mSec Output voltage rise time from each main output Delay from AC being applied to 3V3 being within T2 (Tsb_on_delay) - - 2500 mSec regulation Delay from AC being applied to all output voltages being T3 (Tac_on_delay) - - 3000 mSec within regulation Time all output voltages, including 3V3, stay within T4 (Tvout_holdup) 16 - - mSec regulation after loss of AC T5 (Tpw_ok_holdup) 5 - - mSec Delay from loss of AC to de-assertion of PW_OK Delay from PS_ON active to output voltages within T6 (Tps_on_delay) - - 400 mSec regulation limits Delay from PS_ON de-active to PW_OK being de- T7 (Tps_on_pw_ok) - - 50 mSec asserted T8 (Tac_ok_off) - - 20 mSec Delay from loss of AC input to de-assertion of AC_OK Delay from output voltages within regulation limits to T9 (Tpw_ok_on) 100 - 1000 mSec PW_OK asserted at turn on Delay from PW_OK de-asserted to 12VDC dropping out of T10 (Tpw_ok_off_12V) 1 - 700 mSec regulation limits Delay from PW_OK de-asserted to 3V3 dropping out of T11 (Tpw_ok_off_3V3) 20 - - mSec regulation limits Delay from 3V3 being in regulation to 12VDC being in T12 (Tsb_vout) 50 - 1000 mSec regulation at AC turn on. T13 (Tac_ok_on) - - 1500 mSec Delay from AC being applied to assertion of AC_OK Table 11.Timing Table The I2C interface should be isolated from primary circuits and be SELV rated. Provision is made to accommodate ground level shift between system I2C ground and the supply’s internal signal ground. The I2C circuitry becomes active upon application of AC power at the input, or output to the supply. Inhibiting the output shall not affect the power to the I2C. The signal transition region between 1 and 4 volts shall have no more than 50 mv peak-to-peak ringing. Rise and fall of these signals must be monotonic in the 1 to 4 volt region. Refer to software spec. tech.support@psbel.com
Page9

SPAFCBK-14G 9 It is expected that the vendor supports most of the standard set of commands as per the PMBus specification. However, the following set of “standard” commands MUST be supported at the minimum, either through PMBus access or other methods to retrieve the information related to power efficiency. Refer to SPAFCBK-14G PMBus Communication manual for more details about the PMBus Commands sets. COMMAND CODE COMMAND NAME TRANSACTION TYPE COMMENT Turns on/off power supply. 0x01 OPERATION Write Command argument determines ON/OFF 0x88 READ_VIN Read Read input voltage 0x89 READ_IIN Read Read input current 0x8B READ_VOUT Read Read output voltage 0x8C READ_IOUT Read Read output current 0x96 READ_POUT Read Read Output Power 0x97 READ_PIN Read Read Input Power Table 12. PMBus Commands A 32K bit EEPROM device (example: AT24C32CY6-YH-T) is used in the power supply for user information storage. The EEPROM address is determined by PS_A0 & PS_A1 settings. (Address Matrix Table).Write protection is enabled in default to prevent unintended write to the EEPROM. In order to write to the EEPROM, first the write protection needs to be disabled by sending the appropriate command to the PSU (Refer to SPAFCBK-14G PMBus Communication Manual for more details). There will be 2 separate LED indicators, one green and one amber to indicate the power supply status. There will be a (slow) blinking green POWER LED (OK) to indicate that AC is applied to the PSU and the Standby Voltage is available. This same LED shall go steady to indicate that all the Power Outputs are available. This same LED or separate one will blink (slow) or be solid ON amber to indicate that the power supply has failed or reached a warning status and therefore a replacement of the unit is/maybe necessary. The LED are visible on the power supply’s exterior face. The LED location meets ESD Requirements. Power Supply Condition Green (OK) LED Status Amber (FAIL) LED Status No AC power to all power supplies OFF OFF Power Supply Failure (includes over voltage, over current, over OFF ON temperature and fan failure) Power Supply Warning events where the power supply continues OFF Blinking to operate (high temperature, high power and slow fan) AC Present/ 12VSB on (PSU OFF) Blinking OFF Power Supply ON and OK ON OFF Table 13. LED Indicators Approved to the latest edition of the following standards: UL/CSA60950-1, IEC60950-1 and EN60950-1. Asia-Pacific Europe, Middle East North America +86 755 298 85888 +353 61 225 977 +1 408 785 5200 © 2016 Bel Power Solutions & Protection BCD.00649_AA
Page10

10 SPAFCBK-14G Operating -5 +55 Temperature °C Storage -40 +85 Operating (non-condescending) 90 Humidity +5 %RH Storage (non-condescending) 95 up to 40°C 4000 Altitude Operating without derating m up to 55°C 1800 Reliability MTFB (Telcordia) 300 kh PARAMETER STANDARD / DESCRIPTION CRITERIA Class B Radiated Emissions EN55022/CISPR 22 and FCC Part 15 > 0 dB margin Class B Conducted Emissions EN55022/CISPR 22 and FCC Part 15 > 0 dB margin EN61000-3-2 (AC Rated Input Current <=16 A per phase) Harmonics EN61000-3-12 (AC Rated Input Current >16 A and <=75 A per phase) EN61000-3-3 (AC Rated Input Current <=16 A per phase) Voltage Fluctuations and Flicker EN61000-3-11 (AC Rated Input Current >16 A and <=75 A per phase) ESD EN/IEC61000-4-2 (8 kV Contact, 15 kV Air) Criteria A Radiated Immunity IEC61000-4-3 (10 V/m) Criteria A 2 kV Criteria B EFT IEC61000-4-4 (5 kHz and 100 kHz repetition rates) 0.5 kV Criteria A Surge IEC61000-4-5 (4 kV CM, 2 kV DM) Criteria A Conducted Immunity IEC61000-4-6 (10 Vrms) Criteria A Power Frequency Magnetic Field IEC61000-4-8 (30 A/m) Criteria A Voltage dips, short interruptions and voltage IEC 61000-4-11 variations immunity tests Ring Wave IEC61000-4-12 (4 kV CM, 2 kV DM) Criteria A Width 54.5 Dimensions Height 40.0 mm Depth 333.5 M Weight 1.36 kg tech.support@psbel.com
Page11

SPAFCBK-14G 11 27.8 22.14 AIRFLOW DIRECTION 20.89 Figure 2. Side View 1 333.5 ±0.4 321.5 21.24 XLP.02457.0 4.32 Direction of the text 7.82 329.18 ±0.5 Figure 3. Top View 5 26.1 Main PCB 44.04 5.23 Front View Rear View Figure 4. Front View Figure 5. Rear View 13.1 OUTPUT CONNECTOR The output connector is “Hot-pluggable” and interface with DC Power Distribution Board. The output connector shall ensure that the ground signal is connected first, then the power and interface Signals except for a final control signal, such as PSKILL and PRESENT/L which shall be connected last. All connectors shall be capable of 100 insertions. Manufacturer shall ensure that Safety Agency performs additional test, as applicable, to accept connector as suitable for “current interruption” Applications as defined in UL1977. Minimum of 100 “hot” make and break Cycles. Asia-Pacific Europe, Middle East North America +86 755 298 85888 +353 61 225 977 +1 408 785 5200 © 2016 Bel Power Solutions & Protection BCD.00649_AA 3 9.65 Min Both Sides 1 8.2 22.8 0.8 13.8 1.6 4 9.43
Page12
