GF Piping Systems iFIT Installations made simple

iFIT Fewer components, more options System description iFIT is an innovative installation system with a unique iFIT facilitates working across dimensions, i.e. each module modular adapter technology for plumbing and heating. can be connected to pipes of dimensions 16/20 or 25/32. In Thanks to its modular system, iFIT provides more options addition, polybutene and multilayer composite pipes can be using 50% fewer system components compared with used. conventional installation systems. This means low stocking at maximum flexibility. Thus, you can always choose the best option and the most efficient solution for your installation. With the introduction of George Fischer’s iFIT, plumbing technology has taken another step forward. Never before it has been easier and safer to install polybutene and multilayer composite pipes in the dimensions d16, d20, d25 and d32. 2

Benefits Plumbers Home owners and planners Quick and easy installation High operational safety In a few simple steps to a safe connection, thanks to the used The materials used have a high resistance to corrosion and push-fit system lime stone Visual and audible click lock Suitable for all types of installation Window in the adapter and click sound when plugging the Suitable for plumbing and heating installations adapter onto the module Cost effectiveness Fewer components Saving cost thanks to up to 50% fewer components; low 50% fewer components thanks to the modular system storage costs and inexpensive tools Cross-dimensional use Environmentally friendly Each module can be connected to pipes of dimensions 16/20 Installation without external power supply; reusable fittings or 25/32 Cost efficient No expensive tools and low storage costs 3

iFIT High-quality materials, easy installation Specifications Physical properties Multilayer composite pipes Polybutene maximum operating temperature 95 °C / 5 bars 95 °C / 5 bars maximum non-stop operating pressure 10 bars / 70 °C 10 bars / 70 °C thermal conductivity (pipe) 0,43 W / mK 0,32 W / mK pipe roughness 0,007 mm 0,007 mm 4

Piping materials Application and installation The modular adapter system iFIT meets highest economic Diffusion-tight multilayer composite pipe with inner and standards. Conventional installation systems for plumbing outer layer made of PE-RT (temperature resistant and heating usually consist of 250 to 300 components, which polyethylene) with butt welded aluminium for plumbing and makes it sometimes hard for the plumber to have the heating. required part available. The iFIT push-fit system offers a Homogeneous polybutene (PB) all-plastic pipe for plumbing. solution. Thanks to its modular system, the plumber requires only half the components for the same number of applications, thus replacing the twenty most important components of a conventional installation system and reducing storage costs. This additionally and significantly Fitting materials reduces the number of components the technician is required to take along to the installation site. Fittings made of high-performance plastic (PPSU) and of dezincification-resistant, low-lead brass. In almost any situation, the plumbers will have the required component at hand; they will not need to undertake expensive trips to shops or to the warehouse, which in turn is reflected in a significantly higher productivity. Two dimensions (e.g. adapter d16 and adapter d20) can be connected to each base body, which is referred to as a module. This means: A piece can be combined with suitable adapters d16 and d20 to form six different piece variants. 5

iFIT O ptimum comfort thanks to highest quality Example bathroom installation Besides fashionable tiles and modern taps, smoothly working and reliable plumbing is prerequisite to fully enjoy the comfort of your bathroom. Plastic drinking water pipes are a crucial factor. To function properly, water pipes must be durable, reliable and highly corrosion resistant. iFIT is suitable for all types of installation (such as single tap points, piece or looped installation) in new buildings, conversions and reconstruction of small and large properties. 6

Quality assurance and product approval The iFIT system is subject to permanent monitoring by various internal and external testing bodies ranging from quality assurance during production to various ISO certifications concerning environmental and process safety. In addition, iFIT meets the requirements for key applications in building technology and is subject to constant monitoring by a number of approval authorities (such as SVGW, DVGW, ÖVGW, SITAC, GL, DNV, etc.) for drinking water and heating systems both on land and at sea. 7
