GF Piping Systems Gas utilities The reliable solution for your application

The best choice for you Corrosion resistant and flexible system solutions Georg Fischer Global presence GF focuses on three core businesses: GF Piping Systems, Our global presence ensures customer proximity worldwide. GF Casting Solutions and GF Machining Solutions. The Sales companies in 28 countries and representatives in industrial corporation founded in 1802 headquarters in another 80 countries provide customer service around the Switzerland and operates approximately 136 companies clock. With 48 production sites in Europe, Asia and the USA with more than 15 800 employees across 34 countries. GF we are close to our customers and comply with local Piping Systems is a leading supplier of plastic and metal standards. A modern logistics concept with local distribution piping systems with global market presence. For the centers ensures highest product availability and short treatment and distribution of water and chemicals, as well delivery times. as the safe transport of liquids and gases in industry. Complete solutions provider Our market segments Our extensive product range represents a unique form of Being a strong partner, GF Piping Systems supports its product and competence bundling. With over 60 000 customers in every phase of the project in the following products, allied with a broad range of services, we offer market segments: individual and comprehensive system solutions. Our • Building Technology automation offering perfectly fits into our complete system • Chemical Process Industry approach and is thus an integral part of our portfolio. Having • Energy the profitability of the project in focus, we optimize • Food & Beverage / Cooling processes and applications that are integrated into the whole • Microelectronics system. Thanks to our worldwide network customers benefit • Marine directly from over 50 years of experience in plastics. From • Water & Gas Utilities start to finish, we support our customers as a • Water Treatment competent, reliable and experienced partner. 2

Introduction A lifetime of consistent performance The big advantage of plastics like PE (polyethylene), compared to metals is that there is no electro- chemical corrosion. In addition to this, plastic is lighter than other materials. The «Total Plastic Solution» from GF Piping Systems ensures safety in all applications. Safe and reliable processes and workfl ows achieved through the use of plastic piping systems translate into consistently high effi ciency for customers over the entire lifetime of their operations. PE benefi ts at a glance • Corrosion resistant • No extra corrosion prevention required • PE is fl exible during storage and installation • Withstands earth movements best • Smooth surface resulting in higher fl ow rates, reduced energy costs • Good price performance and total cost of ownership • Plastics are generally much lighter in weight • PE is the optimal material for trenchless installation techniques • PE has an estimated lifetime of 100 years • The material is durable, reliable and material homoge- nous jointing technologies are available • PE is “greener” than metal, due to it`s low carbon footprint • Global standards: ISO, ASTM, EN and many more 3

Transport and distribution lines High performance jointing technology for a reliable network Designed for a safe and sustainable gas distribution Transportation lines (> d315 mm) Distribution lines (d75–d315 mm) When transporting gas to the domestic areas a safe and For the reliable, economical and sustainable gas distribution reliable connection is the key success factor, but at the same it is essential that all piping components like pipes, fi ttings time can be a challenging task. GF Piping Systems and valves are connected safely and reliably. understands your need for proper tooling, high performance GF Piping Systems off ers a comprehensive range of jointing jointing technologies and connection parts as well as expert technologies to satisfy your needs. With our electrofusion support on site. It is our experience and know-how in system ELGEF Plus a material homogeneous connection of building, operating and maintaining large dimensioned pipe and fi tting will contribute to a reliable network. This piping systems, that enable us to create the right solutions system includes also all necessary tools and machines for your varied installations in gas transport applications. important for a proper installation. With the MULTI/JOINT 3000 Plus system all kind of pipe material can be connected in a quick, safe and simple way – one size fi ts and grips all. 4

Service lines and house connections Solutions for a safe and fast pipe connection Always the right solution with the modular system of ELGEF Plus Service lines and house connections (d20–d63 mm) In the last stage of the gas grid, service lines transport gas to the meter. Due to its fl exibility and material homogeneous jointing technologies, amongst many other positive characteristics, PE is today’s main used material for new installations. Thanks to the modular ELGEF Plus electrofu- sion system an appropriate solution can be found for every application. Each individual ELGEF fi tting and saddle is made to match and when put together they form reliable leak- proof connections. The outstanding customizing possibilities together with its fl exibility are convincing and decisive customer benefi ts. Many diff erent combinations can be devised using just a few products. Also PE valves will contribute to your reliable and safe network as part of the ELGEF Plus system. 5

Maintenance and repair Complete and flexible maintenance and repair solutions During recent years the gas supply industry has invested greatly to ensure and enhance consistent quality in the operation and maintenance of the gas supply networks. GF Piping Systems continues to provide high quality systems and services for building and maintaining these networks thus contributing to the transportation of gas in the safest, most secure and reliable way. Connecting With MULTI/JOINT 3000 Plus fi ttings you can connect any pipe you like, regardless of the pipe material. Very convenient, when you do not know what kind of pipe materials you will encounter. Moreover thanks to the quick, safe and simple installation of the fi ttings you will always make a reliable connection. Non restraint or restraint! Repairing Also for maintenance or repair of an existing or corroded pipe GF Piping Systems off ers the right solution. With our MULTI/JOINT 3000 plus products and special PE solutions you can virtually repair all pipes. Quick, safe and simple! Tapping Do you want to branch off on an existing pipe or make a bypass? The end users connected to the network should not experience any inconvenience. For this purpose GF Piping Systems off ers an extensive package of universal tapping products, such as drilling tools, saddles and accessories to be able to tap under pressure or pressureless. 6

Jointing Technology Reliable systems for your gas application ELGEF Plus system MULTI/JOINT 3000 Plus system • High quality electrofusion jointing technology from • The quick, safe and simple repair solution d20 mm – d2000 mm for a reliable connection • Max. 8° misalignment per socket end (16°for a coupling) • Modular system with perfectly matching components for • Suitable for all pipe materials and reusable optimized storage and fl exibility on construction site • Applications for under and above ground use • Safe and easy installation due to the proven system and • Restraint up to and including DN600 corresponding machines and tools • Non restraint up to DN2200 Spigot fi ttings Electrofusion machines • Complete jointing technology from one hand, including • One machine for all dimensions butt fusion machines • Quality assurance thanks to traceability, GPS data • Exclusively usage of PE100+ listed raw material collection and QR code function • No pressure derating factor • Wireless welding thanks to PDA (Type MSA 4.1) • Comprehensive portfolio from d20 up to d1200 mm • Management system for fusion protocols and pictures • Extensive range for electro- and butt fusion • Big graphical display and icons for intuitive operation PE Valves Butt fusion machines • Optimal fl ow geometry • CNC technology up to d630 mm • Long spigots for an easy installation • Traceability function • Welded connection to PE pipes • High security during installation due to automatical • Pressure Tapping Valves up to d400-63 mm guided welding process • Ball Valves up to d225 mm • Global network of authorized GF service centers 7

Services We serve your business GF Piping Systems is aware of the fact that our promised performance does not end with a products’ purchase or installation. For us, it is important to provide individual support and application-oriented services along the entire lifecycle of your installation. 8

Non-destructive testing of butt fusion joints and material We provide NDT services during construction, as well as during operation of PE piping systems. This technique is used to evaluate the properties of the joint and the welded components. We provide reports to you of each test including statements (pass / fail) regarding the long term behaviour of the joints. Extended network documentation Knowing exactly which components are buried in the ground and having clustered additional information of the component history is saving money for operation, maintenance and repair. We provide the proper tools for collecting, storing and analyzing component related information of your piping system. On construction site data logging is supported by the GF Trace App running on a PDA. Customizing and rental pools Special fi ttings or prefabrication on request is what makes a solution your solution. Our customizing teams work closely together with our production and engineering specialists around the globe to develop the best solutions for you. In many countries, GF Piping Systems operates rental pools providing you machines and tools for various jointing technologies like butt fusion, electrofusion and mechanical connections. Global trainings GF Piping Systems specialists are always close by. Worldwide, a comprehensive range of training courses is conducted by our local expert teams. The trainings are focused on methods with high practical relevance. Geared specifi cally toward your individual priorities as well as to your level of knowledge, our courses off er a high degree of quality and exclusivity. On site, instructing pipe fi tters in the specifi c aspects of the installation prior to the actual construction work saves valuable time. 9

References The reliable and safe solution to make a branch The responsible use of energy resources is increasingly important in today’s world. Policymakers, industry and business are now more than ever confronted with the challenge of sustainable energy management. On a regional or local level, cities and grid companies must take the targets of the national energy policy into consideration when supplying the public with energy. A secure supply, environmental and climate compatibility as well as economic effi ciency all have high priority. Periodic maintenance and renovation work as well as a GF system for mains from d315 to d2000 mm and outlets in continual expansion of the network infrastructure are d160, d225, d315 and d500 off ered more fl exibility in the prerequisite for a secure regional and interregional supply. application than other systems. Having supplied the city with gas for over 160 years, GASAG represents an important part of Berlin’s history. Together Lateral connection much easier with the grid operator, NBB Netzgesellschaft Berlin- Connecting branch lines to existing pipes in large dimen- Brandenburg (NBB), GASAG maintains a distribution network sions presents a particular problem in renovation projects. of over 13 000 km in Berlin and Brandenburg, safely and With the new ELGEF Plus branch saddle topload, creating reliably supplying over 170 cities and communities with required branch lines, particularly to lines in operation, is energy, making it one of the largest local network operators now easier, safer and more economical – even in situations in Germany. where space is limited. The key advantage of the ELGEF Plus branch saddle topload is that it is based on the time-tested Great system diversity for large dimensions concept of the popular ELGEF Plus modular system. Modular Where pipes in large dimensions are concerned, plastic and multidimensional system components, functional piping systems are the trend. It was therefore not surprising design and a self-explanatory installation principle are fea- that GASAG/NBB relied and still rely on polyethylene (PE) tures which convince suppliers, pipeline constructors and pipes and fi ttings for the renovation of a 1000 mm cast iron installers alike. The peeling tool included in the installation pipeline in Berlin’s city center, which was performed in the set ensures the oxide layer is removed evenly and reproduc- relining method. The construction work on the reference site ibly in the fusion area during prepping. No more impractical was completed by the installation and engineering fi rm and unreliable scraping by hand. The customer benefi ts Märkischen Rohrleitungs- und Anlagenbau GmbH + Co. KG. from the quality of the system, the expertise of the installa- Products from GF Piping Systems were used because the tion partners and the close constructive cooperation of all two companies had already worked together on similar involved in the project. projects with highly successful results. In addition, the 10

References MULTI/JOINT 3000 Plus DN50 – DN600 restraint The fi rst installation of the new restraint MULTI/JOINT 3000 Plus DN400 left a happy customer and a safe feeling. Container storage terminal Unexpected problem For many years Rotterdam has been the biggest and best Shortly before the planned date the gas company did a fi nal equipped port in the world. From all over the world millions check on all required materials and it turned out the DN400 of containers arrive here every year to be distributed over coupling on site was not restraint. An unexpected problem. the rest of Europe. Before these containers can be on their And the installation date could not be moved. way, they have to be stored at so called container storage terminals. From here they are transported further by truck, Not a day too soon train or river vessel. The gas company contacted Georg Fischer N.V. to bring the recently introduced restraint MULTI/JOINT 3000 Plus Undesirable situation DN400 into action. Thanks to the NBR seals the One of these terminals is on an industrial estate in Tilburg. MULTI/JOINT 3000 Plus DN400 fi ttings can also be used in The owner of the container terminal recently purchased the gas pipes up to 5 bar pressure. By mutual agreement it was lot from the municipality of Tilburg. However, a cast iron gas decided to use a fl ange adaptor, combined with an pipe DN400 runs through the ground below the containers. FF-reduction DN400 x DN300. Heavy, stacked containers of which the contents are not always fully clear and a large underground pipe line are not Work safely the most desirable combination. Safety was at risk and an The contractor was very experienced when it comes to the adequate solution needed to be found. various systems of GF Piping Systems and he also had the necessary welding machines and certifi ed personnel. Planned diversion However, the contractor obviously had no experience with The gas company, responsible for the pipe line came with a the newly introduced restraint MULTI/JOINT 3000 Plus solution. They decided to branch off the existing pipe line to a DN400 yet. With hindsight they were particularly happy with new one around the lot and to shut off the pipe line below the not only the easy installation, but also with the lifting eye on lot. In order to realize this diversion and disconnection a new the fl ange adaptor. Considering the weight of the fl ange valve group was needed. For this purpose the existing cast adaptor, the lifting eye made lifting the fl ange adaptor off the iron gas pipe DN400 had to make a restraint connection with pallet and lowering it into the trench a lot safer. Soon after a valve d315 via a cast iron reduction piece. introduction of the new dimensions DN350 and DN400 MULTI/JOINT 3000 Plus all those involved could look back on a successful installation of the fi rst DN400 restraint fi tting. 11
