48.8インチ 高輝度液晶モニター VGA,DVI-D,HDMI入力
■48.8" LCD Ultra Wide Screen (16 : 3.6)
■太陽光の下でも見える高輝度(1400NIT)液晶パネル採用
■低消費電力 84W
仕様
・画面サイズ 48.8インチ
・表示エリア 水平1209.6 x 垂直275.5 mm
・LCDパネル輝度 1400 cd/m2
・表示解像度 1920 x 438
・アスペクト比 16:3.6
・コントラスト比 1500:1
・視野角 水平 178度/垂直 178度
・入力コネクタ VGAx1,DVI-Dx1,HDMIx1
・電源 AC 100~240V
・寸法(WxHx D) 1247.2x 316.1 x 65mm
・重量 13.5Kg
・動作温度 0 ~ 50℃
・無償保障期間 1年間
このカタログについて
ドキュメント名 | LITEMAX Spanpixel SSD4887-B |
---|---|
ドキュメント種別 | 製品カタログ |
ファイルサイズ | 444.8Kb |
登録カテゴリ | |
取り扱い企業 | サンテックス株式会社 (この企業の取り扱いカタログ一覧) |
この企業の関連カタログ
![](https://static.cluez.biz/common/img/base/loading.gif)
このカタログの内容
Page1
SSD4887-B V1
48.8” Resizing LCD,1400 nits LED backlight, 1920 x 438 ultra-wide aspect ratio 16:3.6
The SSD4887-B is a 48.8 inch color TFT-LCD display with special aspect ratio 16:3.6 and wide resolution 1920
x 438. It is Litemax’s Spanpixel series product which designed for high brightness 1400 nits with power
efficiency LED backlight. It provides LCD panel with specific aspect ratios and sunlight readable for digital
signage, public transportation, exhibition hall, department store, and vending machine.
Key Features
Resizing LCD
Ultra-Wide Screen (16 : 3.6)
High Brightness 1400 nits
Sunlight Readable
LED Backlight
Slim Bezel
BL MTBF: 100,000 hours
Specifications
Model Name SSD4887-B V1
Description 48.8” Resizing LCD, 1400 nits LED backlight, 1920x438
Screen Size 48.8”
Display Area (mm) 1209.6(H) x 275.5(V)
Brightness 1400 cd/m2
Resolution 1920x438
Aspect Ratio 16 : 3.6
Contrast Ratio 1500 : 1
Pixel Pitch (mm) 0.63(H) x 0.63(V)
Pixel Per Inch (PPI) 40
Viewing Angle 178°(H),178°(V)
Color Saturation (NTSC) 81%
Display Colors 16.7M
Response Time (Typical) 8ms
Panel Interface LVDS
AD Board Input Interface VGA, DVI-D, HDMI
Input Power AC100~240V
Power Consumption 84W
OSD Key 4 Keys (Power Switch, Menu, +, -)
OSD Control Brightness, Color, Contrast, Auto Turing, H/V Position…etc
Dimensions (mm) 1247.2 x 316.1 x 65
Bezel Size(U/B/L/R) 18.3/18.3/16.8/16.8 mm
Weight (Net) 13.5 kg
Mounting 300X75
Operating Temperature 0 ˚C ~ 50 ˚C
Storage Temperature -20 ˚C ~ 60 ˚C
SSD= Panel+ LED Driving Board + AD Control Board + Housing
Specifications are subject to change without notice.
All brands or product names are trademarks or registered trademarks of their respective companies.
LITEMAX Electronics Inc. Page 1
Page2
Mechanical Drawing
Outline Dimensions Unit: mm
LITEMAX Electronics Inc. Page 2
Page3
LITEMAX Electronics Inc. Page 3
Page4
Ordering Information
Part Number Description
SSD4887-BNB-G01 48.8",1400nits,1920*438,LID48A.AD2662GDHM,O/B,AC100~240V,2IN1,V1
Optional Accessories
Part Number Description
810618301010 CABLE.POWER.AC.1830mm USA type
810618301090 CABLE,POWER,AC,1830mm Europe type
810618301050 CABLE.POWER.AC.1830mm UK type
810618301170 CABLE.POWER,AC,1830mm Australia type
810618301031 CABLE.POWER.AC.1830mm Japan type
By Customer Request
Glass Tempered glass, AR coating……..
LITEMAX Electronics Inc. Page 4
