Multi-Channel Tunable Laser

Product Catalog

The system is a transmission light of DWDM (Dense Wavelength Division Multiplexing), and then output signal wavelength can be set arbitrarily.

The system is a transmission light of DWDM (Dense Wavelength Division Multiplexing), and then output signal wavelength can be set arbitrarily.
Each unit can be equipped with up to 8 channels of laser, and software that can control up to 10 units and 80 channels is included.

Document Information

Document Title Multi-Channel Tunable Laser
Document Type Product Catalog
File size 821.8Kb
Category
Company Think-Lands Co., Ltd (Documents List)

Documents related to this company

Document Contents

Page1

Multi-Channel Tunable Laser TLH-0008 From$6,600 We estimate according to the number of output channels you request. Please feel free to contact us. * Prices vary depending on the exchange rate. Application Feature - Light sources - L-Band and FullF Ce-Baantdu Truenability for optical device testing - Flex Grid - Transmission evaluation - Tunability Step; 0.1 GHz - Optical sensing - Channels Upgrade; 1 to 8 channels/unit - Unit Upgrade; 1 to 5 units, max Channels; 40 - You can choose from 3 types lasers * Please specify which type of laser should be output from which channel. Think-Lands Co., Ltd 75-1 Ono-chou, Tsurumi-ku, Yokohama-shi, Kanagawa-ken Leading Venture Plaza No.1 Building No. 502 Room, 230-0046, Japan Open Mon.-Fri. 8:50 am to 5:00 pm. http://think-lands.co.jp Tel: +81-045-633-4082 Mail: eigyou@think-lands.com
Page2

Mult i-Channel Tunable Laser TLH-0008 Specifications Items C500 L500 C150 Unit Fiber Output Power +7~+15.5 +7~+15.5 +10~+15.5 dBm Wavelength Tuning Range 1528.773~1563.455 1572.063~1608.760 1528.773~1567.133 Nm ITU Frequency Tuning Range 191.750~196.100 186.350~190.700 191.300~196.100 THz Fine Tune Frequency Range +/-5 +/-6 +/-5 GHz Frequency Error Overlife +/-2.5 +/-2.5 +/-1.5 GHz Spectral Linewidth ≦500 ≦500 ≦150 kHz Side Mode Suppression Ratio ≧35 ≧40 ≧35 dB Relative Intensity Noise (10MHz-10GHz,average) -135 -135 -135 dB/Hz Polarization Extinction Ratio >20 dB Over Tuning Range >20 >20 Optical Fiber PMF Optical Connector FC/SPC,SC/SPC Interface 【Front】 【Back】 Power Supply Adaptor Ordering Information X= C500 or L500 or C150 TLH-008-X-Ych-Z Y = 1 - 8 (output channels) Z= S(SC/SPC) or F(FC/SPC) Think-Lands Co., Ltd
