TD-01Portable

Specifications External dimensions 24-bit/1kHz A/D conversion, Portable Digital Indicator Compatible sensors Strain gauge transducer Signal input terminals Round connector(NDIS7P)/terminal bank(connect only one at a time) TD-01Portable Excitation Voltage DC, 2.5 V ±5% (30mA maximum current) Signal input range ±5 mV/V 85mm D/A output ± 2V Calibration range 0.3 mV/V – 5.0 mV/V Equivalent input/TEDS Calibration Within 0.1% F.S. (when using a 1m standard TEAC Φ8, precision 6-core shielded cable with 350Ω impedance, when 5mV/V) For multiple applications, it's easy to check anywhere! Nonlinearity Within 0.01% F.S. + 1 digit (when 5mV/V) Precision Zero drift Within 0.5 μV/°C (input conversion value) Gain drift 0.005%/ºC or less 140mm Graph HI A/D conversion 1000 times/second, 24-bit TEDS 24h OKLists LO Digital filter Moving average Color LCD Waveform Indicator REC Static Strain Interrupt Check Dual Input Compare Continuous Limit (select from OFF, 16, 32, 64, 128, 256, 512, 1024, 2048) operation D/A OUT RoHS 24bit Comparison Output connector BNC Output voltage ±2.0 V Resolution 70.16 μV typ D/A output 68mm Nonlinearity 0.02% F.S. or less Waveform display! Zero drift 0.1 mV/ºC or less Bar meter display! Gain drift 0.003%/ºC or less 35mm TEDS function IEEE1451.4 class 2 mix mode interface Recording & listing Display 2.4" color TFT LCD W85 mm × H140 mm × D35 mm (without protrusions) of indicator values! Display Display modes Setting screens, indicator value digital display, graph display, recorded data list display, static strain display Languages Japanese/English Optional accessories Display range −99999 to 99999 Indicator value Decimal point Display position selectable Calibration Zero calibration/span calibration (TEDS calibration, actual load settings calibration, equivalent input calibration) High limit, low limit, comparison mode, hysteresis, nearly zero, Displayed items moving average, motion detect, zero tracking, digital zero, Function settings digital zero offset, zone definition, hold mode, control lock, minimum grid, digital zero limit, clear digital zero, select data output, D/A converter Sensor value memory Six types of calibration values for each connected sensor Hold functions Sample hold, peak hold, bottom hold, zone definition hold (peak, bottom) Force Measurement in Resistance Welding Carrying case (Soft) CS-TD01S Carrying case (Hard) CS-TD01 300 maximum Indicator value Recorded contents: ID number, date and time, recording mode, sensor value memory number, indicator value Data recording 8 maximum Graph recording Recorded contents: ID number, date and time, sensor value memory number, trigger mode, graph waveform Power supply 4 alkaline or NiMH AA batteries USB bus power (built-in Micro-USB B connector) Operating temperature range 0° to 40°C Storage temperature range −20° to 60°C Operating humidity range 85% RH or less (without condensation) Applicable standards CE marking, VCCI (Class A), FCC (Class A) *TD-01 Portable placed in a hard case External dimensions (W×H×D) Force Measurement for Press FittingApproximately 85 mm × 140 mm × 35 mm (without protrusions) Weight About 320 g (including batteries) TEAC CORPORATION Precaution : To ensure safe handling and operation, read the Instruction Manual before use.Specifications and appearance are subject to change without notice. Company names and product names in this document are the trademarks or 1-47 Ochiai, Tama-shi, Tokyo 206-8530, Japan registered trademarks of their respective owners. E-mail : ipd-cs@teac.jp Web : https://loadcell.jp/en/ TEAC America, Inc., E-mail : datarecorder@teac.com TEAC EUROPE GmbH. E-mail : ipd-sales@teac.eu Pedal Force Measurement TEAC SALES & TRADING (ShenZhen) CO., LTD. E-mail : teacservice@teac.com.cn Load cell site Copyright© 2018 TEAC CORPORATION. All rights reserved. https://loadcell.jp/en/ PRINTED IN JAPAN 0517 BCI-PDF・ISD-074B/TCJ

24-bit /1kHz A/D conversion Portable Digital Indicator TD-01Portable TD-01 Portable is a digital indicator that connects with strain gauge based transducers. This unit displays input signals from transducers as an indicator value or graph display and features: Great visibility with color graphic LCD, high-speed processing A/D converter, indicator recording, interrupt check and support for TEDS. The TD-01 is wonderfully portable and equipped to be highly functional with excellent cost-effectiveness. Force Measurement in Resistance Welding Force Measurement for Press Fitting Pedal Force Measurement A variety of advanced functions are combined in one compact unit! High-performance color graphic LCD screen Waveform & bar meter display function 24h Multiple power supply system D/A output ● The 2.4" color TFT LCD provides great visibility and a variety of ● Continuous operation time on four AA batteries power is approximately ● The analog output corresponds to the unit indicator information. ● Graphical chart allow users to check input signals. 24 hours (when the Premium alkaline batteries are used). value as voltage output of up to ±2V. ● Color changes indicate different alarm conditions. ● USB bus power can enable the unit to drive for many hours continuously. ● Use this unit as a dynamic strain amplifier. USB connection BNC connector connection 24h TEDS TEDS function (Automatic calibration) Indicator value list Data management software TdDataPicker ● TEDS function reads the calibration information automatically ● This function can display a list of recorded indicator values. and records calibration values when the power is turned on. ● Waveform screen can be recorded, displayed and compared. ● Sensor information can be displayed and rewritten. "TdDataPicker* " is the data management software and is included with each TD-01 Portable. "TdDataPicker" allows you to store recorded data in CSV format and shows saved indicator values and graph data by a simple operation. *This software can be downloaded from "TD-01 Portable" product page (http://loadcell.jp/en/products/td-01/). Download service requires member registration. File storage This software can save data recorded in the TD-01 to a computer as CSV format files. Static Strain Disp. Mode Interrupt Check ● Shows the input signal in ● Lead disconnect is immediately micro strain units. revealed on the screen. ● This function makes it easier to ● Lead interruption is detected and check load-cells for plastic the location of the possible deformation. disconnection will be shown in red. USB connection Indicator value list details screen Graph list details screen System requirements Graph Dual Input Lists Compare Readings Recommended PC spec Processor equaling or surpassing an ● Round connector (NDIS7P) ● Record up to 8 different readings for up to 30 sec. Intel Core 2 Duo Computer with 1Gb ● Connecting with the terminal bank ● Select and overlay readings for easy comparisons. or more memory Round connection Leads connection OS supported Windows 7/ Windows 8.1 Windows 10 Indicator values can Display multiple graphs (both 32bit OS and 64bit OS) be easily reviewed on one page
