English PloCompAuto HPGL/Vector/Image Overlay, Compare Converter

PloCompAuto Ver.11.0 - HPGL / Vector / Image Converter - PloCompAuto superimposes multiple drawing files such as printed boards into a single drawing and automatically converts them to PDF, TIFF, etc. at high speed. Also, the drawing area of two drawing files is compared and the change area is automatically and continuously obtained. PloCompAuto will be a very useful tool for electronic library, PDM system construction or design change management. ● Outline ・ Output 1 Input:HPGL, HP-GL/2, HP RTL, PDF, DXF, DWG, GERBER, NC-drill, IGES, SXF, TIFF, JPEG, Bitmap, PCX, FPX, PNG, GIF, EMF, CMT Output:PDF, TIFF, DXF, DWG, JPEG, BITMAP, IGES, SXF, EMF, XPS, PCL, WMF,PS, EPS, SVG, GIF, PNG, PCX, FPX, CMT, HPGL/Printer, PloComp screen Compare the drawings of the two input files, add the changed area, and output. ・ Output 2 Input: PDF Output: WMF, EMF, PS, EPS, SVG, XPS, HPGL, PCL ●Output mode (1) Standby output mode The specified folder is monitored and output when an input file arrives. The input Process flow file is automatically deleted after output. If there is no input file, wait until the file arrives. It also supports drawing comparison. When an input file is received, (3) Drawing comparison between folders is started. (2) Batch file output mode Multiple input files listed in the specified output list file are output continuously. Also supports drawing comparison. You can open multiple input files at the same time. When the output is on screen, start PloComp and display it on the screen. When you exit PloComp, PloComp starts again and displays the following screen. (3) Inter-folder drawing comparison The input files with the same file names in the two specified folders are continuously compared, and the changed area is added and output. PloCompAuto is a set with automatic output special specification version PloComp (hereinafter referred to as PloComp). PloCompAuto generates a command line to start PloComp and has a function to start PloComp. You can also PloCompAuto main dialog start and convert PloComp from your application. PloComp HPGL input, PDF output command line example: PloComp.exe /p ab1.hgl /oab.pdf ●Operating conditions Personal computer with Intel compatible CPU Memory: 1GB or more Free hard disk space: 100MB or more Screen resolution: 1024 dots x 768 dots or more OS: Windows 7, 8, 10,11 32 bits, 64 bits ●License fee 950 US$ / lisense You can try all functions free of charge for 30 days. PloCompAuto drawing comparison PloCompAuto setting dialog sample https://www.isoplotec.co.jp/
